• Use on standing rigging to provide radio antenna

• Guaranteed stronger than the wire rope

• Incorporates Sta-Lok Self fit termination

• Quick and easy to install

• Packed for 1×19 wire as standard

• Manufactured from high specification 316 stainless steel

• Different wedges are available to terminate 7 strand and compacted strand wire ropes

ELECTRICAL PROPERTIES

Impedance Measurement @15MHz, Capacitance 16pF Resistance 400K, D.C.Leakage Resistance @ 30Kv, Greater than 10 G Ohms

Voltage Proof Test – Withstands 30 Kv applied for 2 hours without breakdown. No change in 15 MHz impedance after voltage proof test.
